The JD746A has a standard built-in preamplifier that together with the interference analysis option provides the ability to identify and locate
interfering signals as low as –155 dBm.
The standard features of the JD746A include the following:
• Spectrum Analyzer: 100 kHz to 4 GHz
• Cable and Antenna Analyzer: 5 MHz to 4 GHz
• Power Meter: 10 MHz to 4 GHz
The JD746A was designed with a flexible platform that can support any of the following functions.
• Interference Analysis
• Channel Scanner
• GPS receiver
• 2 port transmission measurements
• Built-In Bias Tee
• CW signal generator
The JD746A is the ideal field testing solution that combines portability, due to its lightweight design and battery extended operation, and
performance, with its multifunction capability.
The JD746A has a strong enclosure design for harsh environments, and its backlight key panel makes nocturnal maintenance tasks possible.
